White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer
Contactless card production
1.White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer- Product Technical Specification
It is mainly used for making radio frequency card. Non-contact IC card is also called radio frequency card. It is mainly used for the automatic fare collection system of public transportation, ferry and underground, and also used for access control, identification paper and electronic purse. Such kind of low-Vicat PVC material can make core in contact with the electronic components better, so as to reduce possible damage and avoid surface irregularities of card.
2. White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer - Application
It is mainly used for making top-grade contactless card. High covering power, capable of providing maximum opaqueness to avoid perspective, it is stiffer and stable more.
3.White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer - Parameters:
| Size | in sheet A4,A3 or custom-made ( ( tolerance +/-0.5mm ) |
| Thickness | 0.12-0.76mm (tolerance +/-5%) |
| Color | Milk White (MOP-W-NF model)/Snow White (MOP-W-F model) |
| Coating description | digital ink coating on one side and lamination glue coating on another side. |
| Package method | 100-200 sheets per PE bag, all the bags are firmly piled up and fixed on the solid plywood pallets. |
| Storage condition | Sealed, moisture-proof, room temperature under 40℃ , Keep it horizontally, avoid heavy pressing and direct sunlight |
4. White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer- Product Features:
| Item | Index |
| Tensile strength | Longitudinal MPa | ≥45 |
| Transverse MPa | ≥40 |
| Vicat ℃ | 77±2 |
| Surface Tension dyne/cm | ≥35 |
| Heat shrinkage rate% 140℃ 10min | Transverse ≤5 |
| Longitudinal ≥-10 |
| Squareness mm | ±1 |
| Thickness tolerance % | ±5 |
| Roughness μm | Ra,μm | 0.7~1.4 |
| Rz,μm | 4~9 |
5. White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer-Characteristics:
Offset printing sheets MOP series are designed for offset printer and silk screen printer use. They can also be used as non-printed middle core sheet. They are massively used by many card factories worldwide.
1) Suitable for the whole series of offset printer and silk screen printer.
2) High definition images.
3) Excellent ink adhesion with strong peeling strength after lamination.
4) No crack occurs on the printed images after lamination at high temperature.
6. White PVC Core Sheet,PVC core offset printable sheet for silk-screen printer - Packing
Product Tags:
|
|
White Printable PVC Sheet For Silk Screen Printer Images
|
